| GAS PRESS FITTING | |||
| MODEL NO. | DESCRIPTION | SIZE | QTY(PCS/CTN) |
| ELS01 | STRAIGHT COUPLING | S16X16 | 320 |
| ELS02 | S18X18 | 224 | |
| ELS03 | S20X20 | 224 | |
| ELS04 | S25X25 | 96 | |
| ELS05 | S32X32 | 80 | |
| S40X40 | 55 | ||
| S50X50 | 40 | ||
| S63X63 | 15 | ||
| ELS11 | REDUCING COUPLING | S18X16 | 320 |
| ELS12 | S20X16 | 240 | |
| ELS13 | S25X16 | 120 | |
| ELS14 | S25X20 | 96 | |
| ELS15 | S32X16 | 80 | |
| ELS16 | S32X20 | 80 | |
| ELS17 | S32X25 | 80 | |
| S40X25 | 60 | ||
| S40X32 | 60 | ||
| S50X25 | 50 | ||
| S50X32 | 40 | ||
| S50X40 | 40 | ||
| S63X40 | 20 | ||
| S63X50 | 15 | ||
| ELS21 | MALE STRAIGHT COUPLING | S16X1/2M | 320 |
| ELS22 | S16X3/4M | 200 | |
| ELS23 | S18X1/2M | 336 | |
| ELS24 | S18X3/4M | 200 | |
| ELS25 | S20X1/2M | 280 | |
| ELS26 | S20X3/4M | 200 | |
| ELS27 | S25X1/2M | 120 | |
| ELS28 | S25X3/4M | 120 | |
| ELS29 | S25X1M | 120 | |
| ELS30 | S32X1M | 96 | |
| ELS31 | S32X11/4M | 90 | |
| S40X1M | 32 | ||
| S40X1 1/4M | 24 | ||
| S40X1 1/2M | 24 | ||
| S50X1M | 24 | ||
| S50X1 1/2M | 24 | ||
| S50X2M | 24 | ||
| S63X1 1/2M | 24 | ||
| S63X2M | 20 | ||
| ELS41 | FEMALE STRAIGHT COUPLING | S16X1/2F | 280 |
| ELS42 | S16X3/4F | 240 | |
| ELS43 | S18X1/2F | 288 | |
| ELS44 | S18X3/4F | 256 | |
| ELS45 | S20X1/2F | 240 | |
| ELS46 | S20X3/4F | 160 | |
| ELS47 | S25X3/4F | 120 | |
| EIS48 | S25X1F | 96 | |
| ELS49 | S32X1F | 96 | |
| ELS50 | S32X11/4F | 64 | |
| S40X1F | 72 | ||
| S40X1 1/4F | 72 | ||
| S50X1F | 36 | ||
| S50X1 1/2F | 36 | ||
| S50X2F | 20 | ||
| S63X1F | 20 | ||
| S63X2F | 20 | ||
| S63X2 1/2F | 20 | ||
| ELS51 | DEMOUNTABLE FEMALE STRAIGHT COUPLING | SH16X1/2F | 320 |
| SH16X3/4F | 288 | ||
| SH18X1/2F | 288 | ||
| ELS54 | SH20X1/2F | 240 | |
| ELS52 | SH20X3/4F | 160 | |
| ELS53 | SH25X3/4F | 120 | |
| SH25X1F | 96 | ||
| SH32X1F | 96 | ||
| ELS61 | COPPER ADAPTER | S16MM-CU15MM | 400 |
| S16MM-CU18MM | 360 | ||
| S20MM-CU15MM | 240 | ||
| S20MM-CU18MM | 240 | ||
| ELS62 | S20MM-CU22MM | 160 | |
| S32MM-CU28MM | 128 | ||
| ELL01 | ELBOW | L16X16 | 192 |
| ELL02 | L18X18 | 192 | |
| ELL03 | L20X20 | 144 | |
| ELL04 | L25X25 | 72 | |
| ELL05 | L32X32 | 48 | |
| L40X40 | 16 | ||
| L50X50 | 16 | ||
| L63X63 | 10 | ||
| ELL11 | FEMALE ELBOW | L16X1/2F | 160 |
| ELL12 | L16X3/4F | 144 | |
| ELL13 | L18X1/2F | 144 | |
| ELL14 | L18X3/4F | 144 | |
| ELL15 | L20X1/2F | 144 | |
| ELL16 | L20X3/4F | 120 | |
| ELL17 | L25X3/4F | 96 | |
| ELL18 | L25X1F | 64 | |
| ELL19 | L32X1F | 48 | |
| L40X1F | 32 | ||
| L40X1 1/4F | 32 | ||
| L40X1 1/2F | 32 | ||
| L50X1F | 28 | ||
| L50X1 1/2F | 20 | ||
| L63X2F | 12 | ||
| ELL21 | MALE ELBOW | L16X1/2M | 192 |
| ELL22 | L20X1/2M | 192 | |
| ELL23 | L20X3/4M | 160 | |
| ELL24 | L25X3/4M | 80 | |
| ELL25 | L32X1M | 48 | |
| SWIVEL ELBOW | |||
| ELL31 | LH16X1/2F | 192 | |
| ELL32 | LH20X3/4F | 160 | |
| ELL51 | WALL-PLATED FEMALE ELBOW | L16X1/2F(A) | 80 |
| ELL52 | L20X1/2F(A) | 96 | |
| ELL53 | L16X3/4F(A) | 96 | |
| ELL54 | L20X3/4F(A) | 80 | |
| L25X3/4F(A) | 80 | ||
| ELT01 | TEE | T16 | 120 |
| ELT02 | T18 | 96 | |
| ELT03 | T20 | 96 | |
| ELT04 | T25 | 48 | |
| ELT05 | T32 | 24 | |
| T40 | 24 | ||
| T50 | 12 | ||
| T63 | 6 | ||
| ELT11 | REDUCING TEE | T20X16X16 | 96 |
| ELT12 | T20X16X20 | 96 | |
| ELT13 | T18X16X18 | 96 | |
| ELT14 | T18X20X18 | 96 | |
| ELT15 | T18X25X18 | 96 | |
| ELT16 | T25X16X25 | 48 | |
| ELT17 | T25X20X25 | 48 | |
| ELT18 | T32X16X32 | 40 | |
| ELT19 | T32X25X32 | 40 | |
| ELT20 | T25X16X16 | 48 | |
| ELT21 | T25X16X20 | 48 | |
| ELT22 | T25X20X20 | 48 | |
| ELT23 | T25X25X20 | 48 | |
| ELT24 | T32X16X25 | 40 | |
| ELT25 | T32X32X25 | 40 | |
| ELT26 | T32X25X25 | 40 | |
| ELT27 | T32X20X32 | 40 | |
| ELT28 | T32X25X20 | 40 | |
| T32X25X32 | 40 | ||
| T40X20X40 | 32 | ||
| T40X25X40 | 32 | ||
| T40X32X40 | 32 | ||
| T50X32X50 | 20 | ||
| T50X40X50 | 18 | ||
| T63X40X63 | 10 | ||
| ELT31 | FEMALE TEE | T16X1/2FX16 | 96 |
| ELT32 | T16X3/4FX16 | 96 | |
| ELT33 | T18X1/2FX18 | 96 | |
| ELT34 | T18X3/4FX18 | 96 | |
| ELT35 | T20X1/2FX20 | 96 | |
| ELT36 | T20X3/4FX20 | 80 | |
| ELT37 | T25X1/2FX25 | 48 | |
| ELT38 | T25X3/4FX25 | 48 | |
| ELT39 | T25X1FX25 | 48 | |
| ELT40 | T32X3/4FX32 | 32 | |
| ELT41 | T32X1FX32 | 24 | |
| T40X3/4FX40 | 16 | ||
| T40X1FX40 | 16 | ||
| T40X1 1/4FX40 | 20 | ||
| T50X1 1/2FX50 | 16 | ||
| T63X2FX63 | 6 | ||
| END CAP | D16 | 480 | |
| D20 | 320 | ||
| D25 | 240 | ||
| D32 | |||
| WALL-PLATED MALE ELBOW | DN16 X 1/2" MI- 65mm | 80 | |
| DN16 X 1/2" MI -90mm | 70 | ||
| DN16 X 1/2" MI- 95mm | 64 | ||
| DN20 X 1/2" MI- 65mm | 80 | ||
| DN20 X 1/2" MI- 90mm | 70 | ||
| DN20 X 1/2" MI- 95mm | 80 | ||
| DN20 X 3/4" MI- 65mm | 80 | ||
| DN20 X 3/4" MI- 90mm | 70 | ||
| DN20 X 3/4" MI- 95mm | 64 | ||
| DN20 X 3/4" MI- 100mm |
48 | ||
| DN16x1/2" MI-150mm | 50 | ||
| DN16x1/2" MI-200mm | 50 | ||
| DN20x1/2" MI-150mm | 50 | ||
| DN20x1/2" MI-200mm | 50 | ||
| DN20x3/4" MI-150mm | 40 | ||
| DN20x3/4" MI-200mm | 40 |
Product characteristics
EFIELD brass press gas fittings are made of CW617N, CW602N and domestic high quality brass raw material and others customer's request.
Conformed to ISO 21003, AS/NZS4176, ISO 17484, EFIELD press fittings have been passed CE, AENOR, SAI GLOBAL, APPROVALMARK certification.
The sleeve is made of stainless steel 304, designed in accordance with mechanical pressing formability and marked with diameter of the pipe. Observation three holes ensusre proper installation of the pipe.
The O-rings are made of EPDM and NBR, EPDM is applicable to water and NBR for natural gas.
Product Execution Standards
