Product Introduction Product Specification

ISO21003/ASTM F1281/AS4176                             Qty/Package

Spec.

Wall thickness( mm)

Length/M

12

1.5

100/200/500

14

2.0

100/200/500

15

2.0

100/200

16

2.0

100/200

18

2.0

100/200

20

2.0

100/200

22

2.5

100/200

25

2.5

50/100

26

3.0

50/100

32

3.0

50/100

40

4.0

4/5/50

50

4.5

4/5

63

6.0

4/5

75

7.5

4/5



Product characteristics

Multilayer pipe is five-layer pipe combines the advantages of metal and plastic pipe, while eliminating the disadvantages of both material.

Absolutely diffusion tight, the aluminum core is continuously overlapped or butt-welded, prevents oxygen and gases from permeating into the pipes.

Easy flexibility, can be bent without being heated, use less fittings

Light weight, easy to transport and quick to install

High pressure capacity, aluminum thickness requirements of ASTM standards

Low thermal conductivity, 0.45W/m.k, about 1/100 of the steel pipe, best for hot water supply than metal pipe

Corrosion resistance, resistant to acid, alkaline and salt solutions

Healty and clean, no harmful substances, mould-proof, non-rusting and non-scaling



Product Execution Standards
